Air Brake Fittings Products

Types of Pipe Fittings:

Quick Inquiry

D.O.T. For Copper Tube Air Brake Fittings Nylon Tube Air Brake Fittings Air Brake Hose Ends Fittings
Materials CA360, CA345, CA377 CA360, CA345, CA377 CA360, CA345, CA377
Vibration Resistance Excellent Excellent Excellent
Working Pressure 150 PSI Maximum based on tubing size ALWAYS consult tubing specifications 150 PSI Maximum based on tubing size ALWAYS consult tubing specifications 225 PSI Maximum based on hose size ALWAYS consult hose specifications
Conformance Meets requirements of SAE and DOT as indicated by configuration Meets requirements of SAE and DOT as indicated by configuration Meets specifications of DOT FMV SS571 when used with SAE J1402 air brake hose
Applications Air brake systems on heavy trucks and trailers that are plumbed with copper tubing Air brake systems on heavy trucks and trailers that are plumbed with nylon tubing. ng must be able to be flared. Air brake systems on heavy trucks and trailers that are plumbed with SAE J1402 air brake hose
Temperature Range 40 to +200F -40 to +200F -50 to +212F
-40 to +93C -40 to +93C -45 to +100C
